NorTide Stainless Steel pushbutton 12V / 24V 20A IP67 green LED | 19mm Silver

Sold out
€19.00

Upgrade your dashboard with NorTide – The Perfect Stainless Steel Switch for a Luxury Look and Reliable Functionality!

Specifications:

  • IP67 waterproof - Dustproof and submersible
  • Made of Stainless Steel 316 - Salt water? No problem!
  • 12V / 24V multivoltage - Suitable for all boats!
  • Switches up to 20A - No need for bulky relays anymore.
  • Available with connector - for easy connection in your boat or camper
  • Momentary or Latching - Suitable for, for example, a horn (momentary) or lighting (latching)
  • Available in many colors
  • CE-Approved
  • EAN code: 6091016327384

Scroll down for more information!

NorTide Stainless Steel pushbutton 12V / 24V 20A IP67 green LED | Silver

Technical properties
Installation diameter                                  19mm
Outer diameter                                              22mm
Voltage                                                              12V/24
Maximum current                                        20A
Color LED                                                        Red
Contacts                                                          1X NO
Switching                                                        Momentary or latching


Material properties
Housing material                                        Anodized aluminum
Knob material                                              Silver Alloy
Contact material                                         Plated silver
Base material                                               PBT

Environmental properties
IP value                                                           IP67
Operating pressure force                        3 - 5N
Nut tightening torque                              5 - 14Nm

Electrical properties
Operating temperature:    -10 to +50 °C
Mechanical life:                     55,000 cycles
LED Lifespan:                          40,000 hours
Front IP Rating:                      IP67 (front)
IP Value rear                            IP65, with connector
Contact resistance               (50mΩ)
Nut tightening torque:        5- 14Nm



Nor Tide Performance Series Overview Pdf
PDF – 1,4 MB 17 downloads

Latching vs Momentary switch

The difference between a momentary and a latching switch:

The difference between a momentary and a latching switch is in how they hold their position:

Momentary switch: Returns to original position when released. For temporary functions, such as a doorbell or horn.
Latching switch: Remains in the selected position (on/off) until you manually reset it. For functions such as lighting.


NorTide Marine Equipment is a brand that specializes in high-quality switches and electronics for various applications. There are many different switches available, but not all switches have the quality you are looking for.

Look no further!
NorTide has an extensive selection of switches of the very best quality, designed with an eye for detail and with the most beautiful appearance. Each type of NorTide switch combines functionality with a stylish design and is carefully selected and tested to meet the highest demands. Whether you are looking for durability, reliability or a refined finish,

With a NorTide push button or switch, you will notice from the first time you press that it is not just 'the first available' switch. These switches immediately give you the feeling of quality combined with robustness. Perfect for use in your boat, RV, machine or other application!

NorTide waterproof Pushbuttons and Switches

Custom made voor the marine environment
